0.635mm Pitch double row 12Pin fixed end
0.635mm Pitch double row 12Pin fixed end

0.635mm Pitch double row 12Pin fixed end

Model NO.
CGZC201-3002B001C1SH
0.635mm PITCH Board-to-Board Floating Connector
Quantity:
Floating RangeX axis, Y axis, Z axis +/-0.7mmInsulation Resistance500MΩMinimum
Pitch0.635mmContact Resistance100mΩMaximum
Pin2*30/2*40 PinMating Cycles100
Insulating bodyLCP（High temperature resistance）, BlackSoldering Temperature260±5℃/5~15 S
Contact MaterialPhosphor bronzeOperating Temperature-40℃~105℃
PlatingUnderlying nickel, Gilded surface（Optional）Mounting MethodSMT
Rated Current0.5A/PinMating Height6.00mm
Rated Voltage50V AC/DCEffective Contact Length1.10mm

Send Message

* clear input
*

Related Products

2.54mm Pitch double row 4Pin floating end
2.54mm Pitch double row 4Pin floating end
Model NO. GZZC202-0202B001C1SF
1.27mm Pitch single row 22Pin fixed end
1.27mm Pitch single row 22Pin fixed end
Model NO. CAEB110-2201BXXXC1SH
6.50mm Pitch double row 8Pin Floating end
6.50mm Pitch double row 8Pin Floating end
Model NO. CBZZ203-0408A001C1SH
6.50mm Pitch double row 8Pin fixed end
