Pitch 2.20mm male chassis dual row 2*4Pin board-to-board connector vertical PCB (SMT)
Pitch 2.20mm male chassis dual row 2*4Pin board-to-board connector vertical PCB (SMT)

Pitch 2.20mm male chassis dual row 2*4Pin board-to-board connector vertical PCB (SMT)

Model NO.
GPZC214-0422B003C1ZF
Quantity:
  • Specification Code:GPZC214-0422B003C1ZF
    90 degree bend angle connector　
    Number of pins 2*4/2*8/2*12/2*20Pin
    Number of rows double rows
    Spacing 2.20mm
    Insulation material LCP (high temperature resistant)
    Contact material brass
    Plating Nickel-plated bottom layer, matte tin surface layer (optional)
    Rated current 3A/Pin
    Rated voltage 250V AC
    Insulation impedance 1000MΩ min.
    Contact impedance 8mΩ max.
    Withstanding voltage 1000V AC/min
    Mechanical endurance 100 times cycle
    Operating temperature -40℃~105℃
    Mounting Perpendicular to PCB board (SMT)
