Pitch 3.30mm male chassis dual row 2*6Pin frame port connector parallel to PCB board (through hole)
Pitch 3.30mm male chassis dual row 2*6Pin frame port connector parallel to PCB board (through hole)

Pitch 3.30mm male chassis dual row 2*6Pin frame port connector parallel to PCB board (through hole)

Model NO.
GPZB211-0602A001R1ZC
Pin pitch 3.30mm male chassis double row total height 5.90mm 2*6P Tinned 90 degree curved pin Frame port connector parallel to PCB board (through hole)
Quantity:
  • Specification Code:GPZB211-0602A001R1ZC
    90 degree bend angle connector　
    Pitch 3.30mm
    Number of rows double row
    Number of PIN 12Pin
    Insulation material Nylon (high temperature resistant)
    Fire rating UL 94-V0
    Contact material Copper alloy
    Plating Bottom layer nickel plated, surface layer tin plated
    Rated current 3A/Pin
    Rated voltage 250V AC/DC
    Withstand voltage 600V AC for 1 minute
    Insulation impedance 1000MΩ min.
    Contact impedance 20mΩ max.
    Mechanical life100 times
    Welding temperature245±3℃/3~5 S
    Operating temperature -40℃~105℃
    Humidity level 1 level
    Installation parallel to PCB board (through-hole)
